sparker156 Posted November 7, 2006 Share Posted November 7, 2006 Hi forgive my lack of knowledge but I am becoming rather confused over which type of engine I can fit in a westfield, and indeed which model of Sierra or Saphire I should be looking for? I think I am after a 2.0L- Zetec? OHC? or DOHC? Quote Link to comment Share on other sites More sharing options...
combatsapph Posted November 7, 2006 Share Posted November 7, 2006 If your building an SDV, then you'll be looking for a 2.0 ohc engine'd Sierra, typically 1990 or earlier. The engines are commonly refered to as a "Pinto". Looks like this (obvisouly you donor may have carbs or fuel injection so may look slightly different). However, Pinto's are not the only engines that can be fitted to a Westfield and if you aren't on a budget, there are probably better engines to use. Quote Link to comment Share on other sites More sharing options...
peterrosey Posted November 7, 2006 Share Posted November 7, 2006 Most Sierras came with the Pinto engine - heavy cast iron block, 8V head. Later versions had a twin overhead cam version. However, a better option for a budget build would be to use a Mondeo engine (1.8 or 2.0-litre) mated up a a Type 9 gearbox (which bolts straight on). The Mondeo engines are plentiful and cheap (£50-£500), while the Type 9 gearbox is available for under £50. All you then need to sort out is the induction kit (carbs and ignition only ecu are the cheapest option). Quote Link to comment Share on other sites More sharing options...
combatsapph Posted November 7, 2006 Share Posted November 7, 2006 Actually, this may be a better photo:- This is a DOHC - probably not very suitable for a kit car, although it has been done but it is more complicated. Quote Link to comment Share on other sites More sharing options...
combatsapph Posted November 7, 2006 Share Posted November 7, 2006 QUOTE Later versions had a twin overhead cam version The only "later" version of the Pinto that had twin cams was the Cosworth YB. The DOHC 8v engines that were later fitted to Sierra's and Granada's share no Pinto design characteristics at all. Quote Link to comment Share on other sites More sharing options...
scruffythefirst Posted November 7, 2006 Share Posted November 7, 2006 Finding a pinto engine'd sierra is becoming increasingly more difficult. Most are now CVH's or DOHC with the mt75 box. Quote Link to comment Share on other sites More sharing options...
JeffC Posted November 7, 2006 Share Posted November 7, 2006 Quote Link to comment Share on other sites More sharing options...
scruffythefirst Posted November 7, 2006 Share Posted November 7, 2006 Whats that for jeff? mowing the lawn? Quote Link to comment Share on other sites More sharing options...
Robandcolin Posted November 7, 2006 Share Posted November 7, 2006 Whats that for jeff? mowing the lawn? Quote Link to comment Share on other sites More sharing options...
V 8 Posted November 7, 2006 Share Posted November 7, 2006 Here we go again Quote Link to comment Share on other sites More sharing options...
JeffC Posted November 7, 2006 Share Posted November 7, 2006 Quote Link to comment Share on other sites More sharing options...
scruffythefirst Posted November 7, 2006 Share Posted November 7, 2006 Quote Link to comment Share on other sites More sharing options...
deano.1 Posted November 7, 2006 Share Posted November 7, 2006 Finding a pinto engine'd sierra is becoming increasingly more difficult. Most are now CVH's or DOHC with the mt75 box. 2.0 DOHC Sierra aint a bad donor if your not planning to use the engine, if you can pick up a GLSi you will end up with discs all round instead of drums at the rear, chuck the engine in the bin and bolt a zetec straight on to the Sierra gearbox Quote Link to comment Share on other sites More sharing options...
scruffythefirst Posted November 7, 2006 Share Posted November 7, 2006 Your stuck with the mt75 then, but other than that, yup Quote Link to comment Share on other sites More sharing options...
sparker156 Posted November 7, 2006 Author Share Posted November 7, 2006 Many thanks for replies Quote Link to comment Share on other sites More sharing options...
